O. Locate the valve cover breather on the pas-
sengers side valve cover. Remove the hose
connecting the breather port on the valve
cover to the port on the throttle body.
P. Plug the throttle body port with the supplied
3/8 rubber cap.
Q. Install the supplied Ø3/8 hose from the valve
cover port and run the hose across the
engine to the future location of the super-
charger inlet.
Q. Remove the plastic oil fill. Insert the oil fill cap
directly into the valve cover. (See Fig. 2-c.)
1. PREPARATION/REMOVAL, cont’d
