16

© 2001 Directed Electronics, Inc. Vista, CA

transmitter/receiver learn routine

The system comes with two transmitters that must be “taught” to the receiver. Use the following learn routine

to program the transmitters, add transmitters to the system or to change button assignments if desired.

IMPORTANT! All remotes that will be used with the system must be programmed at the same time.
Each time the learn routine is accessed and a remote is successfully learned by the system, any
other remotes that had previously been programmed will be erased.

1. Make sure that the system is disarmed.

2. Turn the ignition ON-OFF-ON-OFF-ON. The siren will chirp to indicate that the transmitter is ready to be pro-

grammed.

3. Press the transmitter button(s) that corresponds to one of the Auto-Learn Configurations (1, 2 or 3) in the

table below. Auto-Learn Configuration 1 (separate arm and disarm buttons) is the default setting that the

transmitters come programmed with from the factory.

4. The siren will chirp to confirm that the desired Auto-Learn Configuration has been programmed.

5. Repeat Steps 1-4 until all transmitters have have been taught to the receiver.

The learn routine will be exited when the ignition is turned off or if 10 seconds elapse between programming

steps. The siren will emit a short chirp and then a long chirp to indicate that the learn routine has been exited.

FOR

PRESS

AUTO-LEARN

TRANSMITTER

BUTTON I

BUTTON II

BUTTONS I AND II

CONFIGURATION

BUTTON(S)

FUNCTION

FUNCTION

FUNCTION

1

I and II

Arm only, Panic

Disarm, Channel 2

Channel 3

2

I

Arm, Disarm, Panic

Channel 2

Channel 3

3

II

Channel 2

Arm, Disarm, Panic

Channel 3
