UVP TB-106 Transilluminator UV Blocking Cover - Manual (Page 3)

Installation Procedure
1. With the UV blocking cover hinges facing toward the front of the unit, replace the
transilluminator filter frame on top of the body of the transilluminator.
2. Reinstall the four Phillips-head screws and washers on the sides of the transilluminator to
secure the transilluminator filter frame to the transilluminator body.
Technical Support
Contact UVP Technical Support for additional assistance:
If you are in North America, South America,
East Asia or Australia:
If you are in Europe, Africa,
Call (800) 452-6788 or (909) 946-3197, and ask for
Technical Support during regular business days, between
7:00 am and 5:00 pm, PST.
the Middle East or Western Asia:
Call +44(0) 1223-42002, and ask for Customer Service
during regular business days between 8:30 am and 5:30
pm.
E-mail your message to: [email protected] or
[email protected]
E-mail your message to: [email protected]
Fax Technical Support at (909) 946-3597
Fax Customer Service at
+44(0) 1223-420561
UV Blocking
Cover Hinges
Phillips-Head
Screw and
Washer
UV Blocking
Cover
Transilluminator
Body
