© SurgeX | Technical Support: 800-645-9721 | surgex.com Page 28
On-Line UPS User Manual
Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL
SX-BDL-1500, SX-BDL-2000
120V MODEL
SX-BDL-1500
UPS-1500-OL
SX-BDL-2000
UPS-2000-OL
UPS-2000-OL
PHYSICAL Dimensions W x D x H (inches)
Unit Dimensions 17.3" x 25.6" x 3.4" 17.3" x 21.7" x 5.2"
Shipping Dimensions 22.3" x 31.4" x 9.2" 22.3" x 27.4" x 11.0"
Unit Weight 57.3 lbs 79.4 lbs 81.6 lbs
Shipping Weight 68.4 lbs 91.5 lbs 93.7 lbs
Line Cord 5-15P 5-20P L5-30P
Receptacles
(6) NEMA 5-15R
(1) NEMA L5-20R
+ (4) NEMA 5-20R
(1) NEMA L5-30R
+ (4) NEMA 5-20R
Communication
Interface
RS-232 or SNMP (optional card)
Included in box
UPSILON CD, horizontal brackets, 5:1 brackets, manual, 6ft
DB9 cable
ENVIRONMENT Operating
0 - 40ºC (32 - 104ºF)
Temperature
Audible Noise
< 50dba at one meter
Altitude 11,500 ft (3500 m) above sea level
WARRANTY Warranty Three years electronics / Three years battery
APPROVALS North America UL cUL FCC
INDICATORS &
ALARMS
LCD Visual Display
Input/output voltage & frequency, on-line mode, back up
mode, battery capacity, load level
Audible Alarm Beep every 4 sec (on battery)
UPS Fault Continuous beeping sound and LCD display
