On-Line UPS
User Manual
Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL
SX-BDL-1500, SX-BDL-2000
Table of Contents
1.
EMC Statements – FCC Part 15
3
2.
Important Safety Instructions
4
3.
Introduction
6
4.
Product Description
6
Double Conversion On-Line Technology
6
Diagnostic Tests
7
5.
System Configuration
7
LED Descriptions
9
LCD Descriptions
10
RS-232 Standard Interface
10
SNMP Communications Option
11
Remote Emergency Power Off (REPO) Port
11
6.
Determining the Power Requirements of Your Equipment
11
7.
Hardware Installation Guide
12
Installation
13
Standard Brackets
13
19” Cabinet Ear Installation
13
Vertical Installation Steps
14
Wall-Mounted Installation Steps
14
19” Rack Mount using5 in 1 bracket
15
8.
Rackmount Installation Steps
16
UPS Rail Installation Instructions for 19” Cabinet
16
9.
Initial Connection and Startup
19
10.
User’s Operations
22
Turning Off the UPS when connected to an AC Source
22
Starting the UPS from a DC source (cold start)
22
Turning off the UPS when in DC Mode
22
Self Test Operation
23
Audible Alarm silence in DC Mode or Fault Mode
23
11.
Batteries
23
Replacing the Battery
23
12.
Troubleshooting
25
