Page 21
16
Installation
StorCase Technology, Inc.
InfoStation 9-Bay Installation Guide - Rev. B00
Figure 15: Removing the Module Option Cover Plate
Phillips F.H. Screw
(4 Total)
Module Option
Cover Plate
IFS9_2
Installing the Dual RAID Controller Module Unit
1.
Carefully slide the Dual RAID Controller Module Unit into the chassis and tighten the
two (2) captive screws (Figure 16).
Captive
Screw
(2 Total)
InfoStation Chassis
Dual RAID Controller
Module Unit
IFS9_11
Figure 16: Installing the Dual RAID Controller Module Unit
