Figure 12: dual-channel rear panel configuration, Figure 13: dual-channel backplane configuration – StorCase Technology 9-Bay 4U SCSI Ultra320 User Manual
Page 18
InfoStation 9-Bay Installation Guide - Rev. B00
StorCase Technology, Inc.
Installation
13
Figure 13: Dual-Channel Backplane Configuration
I/O
Module
Jumper
Block
I/O
Module
Jumper
Block
Terminator
Block
IFS14_21
Terminator
Block
Figure 12: Dual-Channel Rear Panel Configuration
IFS14_33
Module #1
(Channel 1)
Module #2
(Channel 2)
InfoStation Rear
