DE300i-SW User's Guide - Rev. A01 StorCase Technology, Inc.
Appendix B - Factory-Installed Options 23
Carrier Installation
Follow the procedures below to install the DE300i-SW Carrier into the receiving frame equipped
with the Hot Swap option.
1. Install the Carrier into the Receiving Frame. A "u" will be present on the front panel.
2. Turn the key lock mechanism, located on the front of the receiving frame, counter
clockwise to the ON position. This locks the drive into the receiving frame and activates
the Hot Swap Board. The drive will begin to spin up and the unit number on the display
will begin flashing.
3. After a short length of time the unit display will stop flashing, indicating that the device
is ready to be used.
