StorCase Technology, Inc. DE300i-SW User's Guide - Rev. A01
14 Installation
Figure 10: Unit ID Select Switch Location
WARNING: Unlocking the carrier unit switches DC power off to the drive. Since drives
require a short amount of time to spin down, allow at least 15 seconds before pulling
the carrier unit out of the receiving frame to avoid possible damage to the drive.
3. A "u" will be displayed once the drive has completed spin down and is ready to be
removed from the receiving frame. The indicator will return to the SCSI ID number when
the carrier is removed from the receiving frame.
4. Use the alignment tool supplied with the DE300i-SW to select the ID number of the disk
drive. Refer to Figure 10 for the location of the unit ID select switch inside the receiving
frame.
WARNING: Selecting an invalid ID number, or selecting the same unit ID number on different
devices may cause unpredictable results and the computer system may not
recognize the installed device(s). If the computer system can not recognize
the boot disk, the computer system may fail to start-up properly.
5. After selecting an appropriate unit ID number, replace the DE300i-SW carrier in the
receiving frame, and LOCK IT IN PLACE.
6. If the DE300i-SW has been installed into an external expansion chassis, verify that
power is on to the chassis and that the last device in the SCSI daisy chain is properly
terminated.
7. Reboot the computer system.
