16 Appendix A - Specifications/Dimensions
StorCase Technology, Inc. PATA DE110 User's Guide - Rev. C03
Appendix A - Specifications/Dimensions
Chassis Reliability/Maintainability
MTBF
500,000 Hours
Preventive
Maintenance
None
MTTR 5 minutes
Environmental
Specifications Operating Storage
Ambient Temperature
0° C to 50° C -40° C to 70° C
Relative Humidity (1)
10% to 80% 10% to 90%
Altitude
-1000 to 10,000 ft -1000 to 40,000 ft
-305m to 3048m -305m to 12195m
Shock (2) 10g 60g
(1)
Non-condensing with maximum gradient of 10% per hour.
(2)
11 msec pulse width 1/2 sine wave.
Physical Specifications
Height
Width
Depth 1.52” (38.6mm)
4.73” (120.1mm)
Weight
Receiving Frame Carrier
8.66” (219.9mm)
5.81” (147.6mm)
1.61” (40.9mm)
7.94” (201.7mm)
1.3lb (0.59kg)
1.4lb (0.64kg) (1)
(1) With carrier removed.
0832a
Electrical Specifications
Input
+5V 65mA
+12V 400mA
