StorCase Technology DE110 User Manual
Page 17
10
Installation
StorCase Technology, Inc.
PATA DE110 User's Guide - Rev. C03
Figure 8A: Receiving Frame Mounting Holes
Mounting
Holes
(Right)
Mounting
Holes
(Left)
0837
Mounting
Holes
(Bottom)
Front of Unit
4.
Adjust the front of the receiving frame so the carrier slides freely in and out on the
receiving frame guides. The position of adjoining peripheral units may require ad-
justment.
