10 Installation
StorCase Technology Inc. DE75i-SWC User's Guide - Rev. B00
Open Open Motor spins up on power on
Open Closed Motor spins up only if SCSI
"Start" command is received
Closed Open Drive motor starts spining up
approximately 12 seconds x the
SCSI ID number for each target
drive (12 second minimum)
Closed Closed Reserved
Closed = Jumper installed
Open = Jumper removed
DLST RMST Function
1 GND Ground
2 ID0 SCSI ID
3 GND Ground
4 ID1 SCSI ID
5 GND Ground
6 ID2 SCSI ID
7 GND Ground
8 ID3 SCSI ID
9 GND Ground
10 DT Disable Onboard Terminator
11 RLEDA Remote LED Anode
12 RLEDC Remote LED Cathode
13 GND Ground
14 DFAULT Force Drive Fault Signal to Display
15 GND Ground
16 SYNC Drive Synchronization Signal
17 GND Ground
18 RMST Remote Start (see Table 3)
19 GND Ground
20 DLST Delay Start (see Table 3)
21 LKB Disable Isolator Function
22 LKA Disable Isolator Function
Table 3 - Option Pins 17-20 Drive Motor Control
Table 2 - Option Pin Connector Signal Descriptions
Pin Signal Function
