-11-
Flash
Pattern #
Pattern
Type
Pattern Description CPS
Shortcuts
(Hold Red w/Green
wire to ground for:)
1 K Flicker † 1 3 Sec (Non-Rotating Only)
2 L Fast Doubleflash 3.3
3 M Tripleflash † 2.5
4
N
A5
PSU Flicker (Non-Rotating Models)
CCW Rotation 1 (Rotating Models) † 0.7
1.3 3 Sec
(Rotating Only)
5
O
A6
PSU Random (Non-Rotating Models)
CCW Rotation 2 (Rotating Models) 0.6
2.7
6 F Quadflash †‡ 1 6 Sec
7 G Quadflash w/Post-Pop †‡ 1
8 H Singleflash †‡ 1
9 I Doubleflash †‡ 1
10 J Variable AKA Delta-Omega 0.3
11 C Post pop 1.4CPS † 1.4
12 E Random 0.4CPS 0.4
NA Steady NA 9 Sec
† - Approved patterns for SAE J845
‡ - California Title 13
(LED Pattern Programming cont’d)
360º Halo™ Flash Patterns
(touch Red w/Green to ground)
LED Pattern Selection for 360º Halo Heads (touch Red w/Green to ground)
1. Power up the LED heads..
2. Touch and release the Red w/Green stripe wire to ground to scroll through the patterns
listed below. The cycle will repeat itself after the last pattern.
3. Once you find the pattern you wish to select, leave the Pattern Select wire disconnected
and turn the LEDs off.
