Installation and instruction manual
PLIT447 REV. B 6/15/12
INSTALLATION AND INSTRUCTION MANUAL
These lights are standard negative ground. Isolated or floating units for
positive ground vehicles are clearly labeled and are available upon request.
In this case connect the power to the proper polarity as marked on the wires.
Please Note: These instructions are provided as a general guideline only. Specific mounting, wiring, and/
or weather-sealing may be necessary and are the sole responsibility of the installer. Star Headlight &
Lantern Co., Inc. assumes no responsibility for the integrity of the installation for this or any of its products.
200AHL and 200AH8L Series 360° LED Lights
(4-LED Non-Rotating)
(8-LED Rotating)
featuring the
CAUTION: All of our DC powered warning lights are polarity sensitive.
These lights are polarity protected only if the appropriate fuse is used.
All wires connected to the positive terminal of the battery should be
fused at the battery for their rated load. Testing the light before this
fuse is properly installed will void the warranty on the light.
