Star Headlight & Lantern 7400 Star Lase User Manual
Page 3
-ii-
NOTICE
Due to continuous product improvements, we must reserve the right to change any
specifications and information, contained in this manual at any time without notice.
Star Headlight & Lantern Co., Inc. makes no warranty of any kind with regard to this
manual, including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose. Star Headlight & Lantern Co., Inc. shall not be liable
for errors contained herein or for incidental or consequential damages in connection
with the furnishing, performance, or use of this manual.
Please Note: These instructions are provided as a general guideline only. Some
vehicles may require special mounting, wiring, and/or weather-sealing. This is the
sole responsibility of the installer. Star Headlight & Lantern Co., Inc. assumes no
responsibility for the integrity of the installation for this or any of its products.
Table of Contents
WARNINGS
i
MOUNTING INSTRUCTIONS
1
WIRING INSTRUCTIONS
1-6
Wire Connections
2-5
Control Wire Harness
2
Power Wire Harness
3
Quick Setup Basic Diagram (Sample Wiring Connections)
3
Control Wire Colors Diagram
4
Wire Harness Replacement
5-6
OPTIONAL LED HEAD PROGRAMMING
7-8
Phase Selection
7
LED Flash Patterns
8
OPTIONAL TAKEDOWN/WORKLIGHT PROGRAMMING 8-9
TRAFFIC DIRECTOR SETUP
10-13
Jumper Settings
10
Internal Traffic Director Controller Wiring and Programming:
11-12
External Traffic Director Controller Wiring and Programming:
13
PARTS
14
SWITCHES
15
TROUBLESHOOTING
16-18
WARRANTY
19
SERVICE
19
