WOOL as any particles left on the surface will rust and further spoil the appearance of the finish. NEVER USE A WIRE
BRUSH, STEEL SCOURING PADS (EXCEPT STAINLESS), SCRAPER, FILE OR OTHER STEEL TOOLS. Surfaces
which are marred collect dirt more rapidly and become more difficult to clean. Marring also increases the possibility of
corrosive attack. Refinishing may then be required.
“Heat tint” is darkened areas that sometimes appear on stainless steel surfaces where the area has been subjected
to excessive heat. These darkened areas are caused by thickening of the protective surface of the stainless steel and
are not harmful. Heat tint can normally be removed by the foregoing, but tint which does not respond to this procedure
calls for a vigorous scouring in the direction of the polish lines using SCOTCH-BRITE scouring pads or a STAINLESS
scouring pad in combination with a powered cleanser. Heat tint may be lessened by reducing heat to equipment during
slack periods.
B
LACK
B
AKED-
E
NAMEL
S
URFACES
Allow appliance to cool somewhat after use and wash black baked-enamel surfaces with a hot, mild detergent or soap
solution. In particular, clean off all grease deposits. Dry thoroughly with a dry cloth.
O
PEN-
B
URNERS
A
ND
G
RATES
The grates can be removed and cleaned with a solution of hot water and strong soap or detergent. The burners
themselves require little attention, but if spillage should occur, it may be necessary to clean around pilot areas, air mixer
and under burners. Use a wire brush if necessary. Periodically, open-burners should be removed and cleaned. Allow the
interior of the burner to drain, and dry thoroughly before replacing.
H
OT-
T
OP
S
URFACES
Before cleaning hot-top surfaces, allow them to cool. If water is used on hot-tops while they are still hot, they may crack,
so avoid this practice. The hot-top plates can be removed and cleaned with hot water and detergent. A wire brush
may be used on the underside of the hot top plate. It is recommended not to clean tops while still on the range, even if
cooled, as excess water will drip into the burner box and deteriorate the metal.
C
ARE
O
F
G
RIDDLES
A griddle should be carefully cared for in order to avoid possible damage. (The griddle should have been tempered as
part of the installation procedure, see page 28). Use a Norton Alundum Griddle Brick to clean the griddle. Do not use
any type of steel wool. Small particles may be left on the surface and get into food products. Do not clean spatula by
hitting the edge on the griddle plate. Such action will only cut and pit the griddle plate, leaving it rough and hard to clean.
O
VEN
I
NTERIOR
WARNING
FOR YOUR SAFETY, DISCONNECT THE POWER SUPPLY TO THE SECTIONAL RANGE BEFORE CLEANING
THE OVEN. WHEN CLEANING THE BLOWER WHEEL OF A CONVECTION OVEN, BE SURE TO HAVE THE
POWER SWITCH IN THE “OFF” POSITION.
To clean the oven interior, first allow the oven to cool. Remove oven bottom and clean it by rubbing with strong detergent
and a Brillo pad or similar scrubber. “Spillovers” should be cleaned from the bottom as soon as possible to prevent
carbonizing and a “burnt-on” condition. For stubborn accumulations, commercial oven cleaners are recommended.
The porcelain oven door lining can be cleaned in a similar manner. The side, rear and top lining should be wiped only with
a cloth dampened with a mild detergent and water. Avoid using excessive amounts of water, as this may drip into burner
compartment and deteriorate the metal in that area. Do not use strong commercial cleaners or abrasive pads on the side,
rear or top linings, as they may damage the finish or leave gray residue
