Sioux Tools NO. 2S - Manual (Page 17)

17
1. 65009 Screw—M4 x .7 (10)*
2. 21491 Ring—Retainer
3. 68235 Ass’y—Housing (Drill)
68268 Ass’y—Housing (Screwdriver)
4. 44383 Shaft—Cluster Gear
5. 30235 Pin—Roll 3/32" x 3/8"
6. 35098 Washer (3)*
7. 10041 Bearing—Needle (2)*
8. 19319 Ass’y—Gear & Bearing (1600 RPM Reversing)
(2200 RPM Non-Reversing)
68231 Ass’y—Gear & Bearing (2200 RPM Reversing)
(3200 RPM Non-Reversing )
19321 Ass’y—Gear & Bearing
(1000 RPM Reversing & Non-Reversing)
(1600 RPM Non-Reversing)
68232 Ass’y—Gear & Bearing (3200 RPM Reversing)
(5000 RPM Non-Reversing)
9. 13202 Spacer—Sleeve
10. 10220 Bearing—Ball
11. 68233 Ass’y—End Plate & Bearing
(1000, 1600, 2200 RPM Non-Reversing)
(1000, 1600 RPM Reversing)
68234 Ass’y—End Plate & Bearing
(3200, 5000 RPM Non-Reversing)
(2200, 3200 RPM Reversing)
12. 64057 Cylinder (1600, 2200, 3200, 5000 RPM
Non-Reversing)
64108 Cylinder (1000, 1600, 2200, 3200 RPM
Reversing)
65916 Cylinder (1000 RPM Non-Reversing)
13. 63192 Vane—Rotor (Set of 5)
14. 54861 Rotor (1000, 1600, 2200 RPM Non-Reversing)
(1000, 1600 RPM Reversing)
68230 Rotor (3200, 5000 RPM Non-Reversing)
(2200, 3200 RPM Reversing)
15. 10552 Plate—Upper End
16. 10230 Bearing—Ball
17. 65008 Gasket
18. 65028 Back Cap (Non-Reversing)
65027 Back Cap (Reversing)
19. 14323 Ring—“O” (1/16" x 1/4" x 1/8")
20. 65016 Ass’y—Speed Control
21. 14371 Ring—“O” (1/16" x 1-5/16" x 1-3/16")
22. 65030 Deflector—Exhaust
23. 54837 Intake Adapter—1/4" NPT
54837Y Intake Adapter—1/4" BSPT
53942 Intake Adapter—1/4" NPT Remote Exhaust
24. 30463 Screen
25. 65040 Pad—Silencer
26. 14312 Ring—“O” (1/16" x 9/16" x 7/16")(4)*
27. 21541 Ring—Retainer
28. 09954 Screw—Drive #0 x 3/16 (2)*
29. 65010 Plate—Name
30. 21401 Spring
31. 14325 Valve
34. 65013 Ass’y—Valve
35. 30499 Pin—Roll 3/32" x 11/16"
36. 65002 Trigger
37. 10104 Bearing—Ball
38. 65014 Gear—Face (1600, 3200 RPM Reversing)
(2200, 5000 RPM Non-Reversing)
65018 Gear—Face (1000, 2000 RPM Reversing)
(1000, 1600, 3200 RPM Non-Reversing)
39. 65001 Spacer—Chuck Spindle
40. 21766 Ring—Retainer
41. 25064 Plate—Chuck Shield (2)*
42. 65000 Spindle—Chuck (Non-Reversing Drills)
65020 Spindle—Chuck (Reversing Drills)
43. 65005 Rod—Valve
44. 25065 Shield (1/4" Chuck)
34213 Shield (3/8" Chuck)
45. 21019A Chuck—1/4"
30202 Key—Chuck (use with 21019A)
21133 Chuck—3/8"
30002 Key—Chuck (use with 21133)
46. 65023 Seat—Valve
47. 65025 Ring—Retainer
48. 65007 Valve—Reversing
49. 65026 Ring—“O” (Teflon)
50. 65022 Spindle—Tool (Stall Drive & Clinch Nut)
51. 10902 Ball—Steel 5/32"
52. 21501 Ring—Retainer
53. 44354 Guard—Collet
54. 44161 Retainer—Ball
55. 21406 Spring
56. 44660 Ring—Guide
57. 57250 Screw—M5 x .8 (Left-hand Th’d)
(1/4 Capacity Chuck)
57250R Screw—M5 x .8 (Left-hand Th’d)
(3/8 Capacity Chuck)
61. 65021 Spindle—Tool (Tools with Clutch)
62. 44353 Adapter—Clutch Case (also used on Clinch Nut
Tools)
63. 1365 Exhaust Tube (Includes Fig. 21 & 64)
(Remote Exhaust)
64. 43210 Ass’y—Spring Clip (Remote Exhaust)
65. 1359 Air Hose (Remote Exhaust)
69. 25074 Washer
70. 65039 Liner—Back Cap (2)*
71. 65006 Valve Body (Non-Reversing)
72. 65038 Bail
73. 21392 Spring
74. 65271 Plunger—Detent
75. 35315 Washer
76. 21447 Bail
Not Shown:
3303 Kit—Remote Exhaust (Includes Fig. 23, 63, 65)
PARTS LIST FOR NO. 2S SERIES SCREWDRIVERS & DRILLS
SERIAL “D”
Fig. Part
No. No. Description
Fig. Part
No. No. Description
FURNISH CATALOG, SERIAL, AND MODEL NUMBER
WHEN ORDERING PARTS
*Order Quantity As Required
