700i Reference Dual-Mono Integrated Amplifier
____________________________________________________________________________________
12
Assigning a custom label to an input:
1. Using the example from the previous page for
configuring an input, repeat steps 1 through 5.
2. When “CUSTOM” appears in the display press
the “OK” button. The display will show
“……………………………” .
3. Rotate the volume control clockwise to scroll
through the 26 letters of the English alphabet,
first in uppercase and then lowercase, followed
by the numbers 0 through 9, and finally several
miscellaneous symbols including the space
character. When you see the letter, number, or
symbol you wish to use, press “OK” to select it
and then repeat this step for the next character.
4. You must assign all 8 characters when creating
a custom input label; If your label requires only
5 characters, you will need to input a blank
space for the remaining 3 characters. Note: If
you decide to create a custom input label for
MiND, it must be spelled exactly as it appears
here – the software is case sensitive.
5. Once you’ve filled the last position, press”OK”
and “SAVED” will briefly appear in the display
followed by “INPUTS”.
6. Press the “Setup” button to exit from the Setup
menu.
The MOON 700i is equipped with a 12 Volt trigger
output. When an input is assigned to the 12 Volt
trigger, the device connected to the trigger will
automatically start-up whenever you switch to that
input. The default setting for all five inputs is on.
When you set the IR input to “Y”, all inputs
previously set to “Y” for that trigger will
automatically be set to “N”. Then the trigger will be
controlled exclusively by an external IR signal. The
following example shows how to configure it:
1. You may either continue where we left off in the
previous example by pressing “Setup” twice to
return to the main menu and the turn the
volume control until “TRIGGER” appears in the
display OR enter into the “Setup” mode from the
beginning by pressing the “Setup” button and
rotating the volume control until “TRIGGER”
appears in the display.
2. Press “OK” and “B1 : Y” will appear in the
display.
3. To disable the 12 Volt trigger, press “OK” and
“B1 ? Y” appears in the display; rotate the
volume control to alternate from “Y” to “N” .
4. Press “OK” and “SAVED” will appear briefly
in
the display followed by “B1 : N”.
5. To configure another input, rotate the volume
control until that input appears in the display,
then press “OK”.
6. Repeat steps 3 and 4.
7. When you have finished with all of the inputs for
the “TRIGGER” press the “Setup” button and
“TRIGGER” will appear in the display. From this
point you can (i) exit from the Setup procedure
by pressing the “Setup” button again and
“EXITING” will appear in the display or (iii)
continue with the Setup procedure by disabling
the infrared remote sensor, changing the IR
codes, resetting the 700i back to factory default
status (see the following examples) or
configuring more inputs (example on previous
page).
