850P Reference Dual-Mono Preamplifier
____________________________________________________________________________________
14
2. Press “OK” and “B1 : Y” will appear in the
display.
3. To disable the 12 Volt trigger, press “OK” and
“B1 ? Y” appears in the display; rotate the
volume control to alternate from “Y” to “N” .
4. Press “OK” and “SAVED” will appear brielfy in
the display followed by “B1 : N”.
5. To configure another input, rotate the volume
control until that input appears in the display,
then press “OK”.
6. Repeat steps 3 and 4
7. When you have finished with all of the inputs for
the “TRIG 1” press the “Setup” button and
“TRIG 1” will appear in the display. From this
point you may go to four different locations in
the Setup menu:
• To configure the second 12 Volt trigger
output, rotate the volume control until
“TRIG 2” appears in the display then press
“OK” and repeat the above process
beginning with step 3.
• To exit from the Setup procedure, press the
“Setup” button again and “EXITING” will
appear in the display.
• To reset the software settings back to their
factory defaults, rotate the volume control
until “RESET” appears in the display (see
the next example).
• To configure the inputs (previous example)
rotate the volume control until “INPUT”
appears in the display.
If you want to control the MOON 850P using a
wired aftermarket infrared remote control receiver
with a universal remote control, you can disable the
IR sensor located on the front panel as follows:
1. You may either continue where we left off in the
previous example by pressing “Setup” twice to
return to the main menu and the turn the
volume control until “INFRARED” appears in the
display OR enter into the “Setup” mode from the
beginning by pressing the “Setup” button and
rotating the volume control until “INFRARED”
appears in the display.
2. Press “OK” and “NORMAL” will appear in the
display.
3. To disable the MOON 850P’s front panel IR
sensor, rotate the volume control to alternate
from “NORMAL” to “DISABLED” .
4. Press “OK” and “SAVED” will appear briefly
in
the display followed by “INFRARED”
5. Press the “Setup” button to exit from the Setup
menu.
The MOON 850P is equipped with a rear mounted
IR input for use with aftermarket wired infrared
remote control receivers. In the event that you want
control the MOON 850P with a universal remote
control and NOT the one included (FRM-3), you can
change the RC-5 remote control system codes. This
procedure is recommended when you have a large
custom install setup that uses multiple integrated
amplifiers and/or preamplifiers that operate on the
RC-5 standard and you need to make each
component unique w.r.t. remote control operation –
up to 4 components. Before making the following
change, you should have a basic understanding
how to program a universal remote control. The
following example shows how to change the IR
codes that the MOON 850P will recognize:
