850P Reference Dual-Mono Preamplifier
____________________________________________________________________________________
13
Only one of the five inputs may be configured for
the MiND. “B1” is the default input. If, in the
previous section, you already assigned the “MiND”
label to one of this preamplifier’s inputs, then there’s
nothing required to do here – The corresponding
input has been automatically configured for MiND
and cannot be changed until you change the input
‘LABEL” assigments. However, if you haven’t
assigned the “MiND” label to one of the 850P’s
inputs, the following example shows how to
configure an input for MiND functionality:
1. You may either continue where we left off in the
previous example by pressing “Setup” twice to
return to the main menu and the turn the
volume control until “MiND” appears in the
display OR enter into the “Setup” mode from the
beginning by pressing the “Setup” button and
rotating the volume control until “MiND” appears
in the display.
2. Press “OK” and “MiND:B1” will appear in the
display.
3. Rotate the volume control clockwise until the
input you want to configure appears in the
display.
4. Press “OK” and “SAVED” will appear brielfy in
the display followed by “MiND”.
5. Press the “Setup” button and “EXITING” will
appear in the display.
Assigning a custom label to an input:
1. Using the example from the previous page for
configuring an input, repeat steps 1 through 5.
2. When “CUSTOM” appears in the display press
the “OK” button. The display will show
“……………………………” .
3. Rotate the volume control clockwise to scroll
through the 26 letters of the English alphabet,
first in uppercase and then lowercase, followed
by the numbers 0 through 9, and finally several
miscellaneous symbols including the space
character. When you see the letter, number, or
symbol you wish to use, press “OK” to select it
and then repeat this step for the next character.
4. You must assign all 8 characters when creating
a custom input label; If your label requires only
5 characters, you will need to input a blank
space for the remaining 3 characters. Note: If
you decide to create a custom input label for
MiND, it must be spelled exactly as it appears
here – the software is case sensitive.
5. Once you’ve filled the last position, press”OK”
and “SAVED” will briefly appear in the display
followed by “INPUTS”.
6. Press the “SETUP” button to exit from the Setup
menu
The MOON 850P is equipped with two 12 Volt
trigger outputs. When an input is assigned to a 12
Volt trigger, the device connected to the trigger will
automatically start-up whenever you switch to that
input. The default setting for all seven inputs is on.
When you set the IR input to “Y”, all inputs
previously set to “Y” for that trigger will
automatically be set to “N”. Then the trigger will be
controlled exclusively by an external IR signal. The
following example shows how to configure one of
them:
1. You may either continue where we left off in the
previous example by pressing “Setup” twice to
return to the main menu and the turn the
volume control until “TRIG 1” appears in the
display OR enter into the “Setup” mode from the
beginning by pressing the “Setup” button and
rotating the volume control until “TRIG 1”
appears in the display.
