ROHO SelectAir MA mattress User Manual
Page 12

0
4. Place the ROHO HIGH PROFILE cushion into the HealFloat foot section of
the mattress overlay.
Note: Refer to the cushion's enclosed operating instructions for proper setup
and adjustment.
5. After inflating the mattress overlay, secure the mattress sheet to the mattress.
6. Remove the ROHO HIGH PROFILE cushion and place on chair to provide
continued skin protection while patient is seated in a chair. Readjust the cushion
for the patient according to the cushion's instructions.
Control Unit - All Models
. Place the control unit handle over the
edge of the footboard. The handle will
self adjust to the width of the footboard
(fig. 3).
. Insert the hose fitting with the clip into
the air outlet of the control unit and turn
/4 turn. Ensure the hose fitting is firmly
seated and that the latch ‘clicks’ into
place (fig. 4).
3. Insert the other end of the hose into the
mattress hose fitting located at the foot of
the mattress (fig. 4).
Figure 4
Section 5
Installation
Figure 3
