NOTICE
- Only licensed Remy International, Inc. product and component parts should be used, and the use of other parts or modifications not approved
by Remy International, Inc. will void all applicable warranties. The failure to carefully follow these Installation Instructions, set forth above, will void all
applicable warranties. DELCO REMY is a registered trademark of General Motors Corporation, licensed to Remy International, Inc. Pendleton, IN 46064.
©
2012 Remy International, Inc. All rights reserved
2
9. Install the large round fiber washer and the remaining parts in the same order as parts were removed. Torque the large nut
on ground stud to 27.0-33.8 Nm (20-25 lb ft).
10. Install clip on OCP connector, if applicable.
11. For 37MT motors, install a new retaining ring into the armature shaft groove and replace the pinion stop. Apply a small
amount of SAE20 oil onto the drive housing bushing and reinstall the drive housing in the same position as removed.
12.
DANGER!!!
Do not reconnect solenoid motor connector strap to field terminal before adjusting the pinion
clearance.
NOTICE! After repair and reassembly it is necessary, before installation on the engine, to check and adjust pinion
clearance. It is recommended the solenoid replacement instruction sheet, be obtained from our website,
13. Reinstall starter and connect cables and other leads, as removed.
14. Reconnect the negative (-) cable at the battery.
