Remy 39MT STARTERS HARDWARE PACKAGES User Manual
Page 2

NOTICE
- Only licensed Remy International, Inc. product and component parts should be used, and the use of other parts or modifications not approved
by Remy International, Inc. will void all applicable warranties. The failure to carefully follow these Installation Instructions, set forth above, will void all
applicable warranties. DELCO REMY is a registered trademark of General Motors Corporation, licensed to Remy International, Inc. Pendleton, IN 46064.
©
2012 Remy International, Inc. All rights reserved
2
Technical support: USA 800 854 0076, Mexico 01 800 000 7378, Brazil 0800 703 3526, South America 55 11 2106 6510 or visit
delcoremy.com
38MT PACKAGE CONTENTS
Description
PART #
QTY
Torque Values
O-Ring
10511919
2
Stop Pinion
10511745
1
Ring Pinion
10511746
1
Spring Pinion
10511744
1
Bolt Solenoid
10516836
2
7.7-9.8 Nm (68-86 lb in)
Solenoid G, B+ and M Terminals Nut
10510842
3
Ground Terminal - 24.5-27.5 Nm (18-20 lb ft)
Solenoid B+ terminal - 24.5-7.5 Nm (18-20 lb ft)
Terminal M - 19.6-22.5 Nm (14-16 lb ft)
Solenoid S Terminal Nut
10517133
1
2.0-2.5 Nm (18-22 lb in)
Roll Pin DE Housing
1875690
1
Bolt IMS
10517131
2
7.7-9.8 Nm (68-86 lb in)
Bolt CE Housing
10516965
2
2.4-3.0 Nm (21-26 lb in)
Spring Washer Solenoid
10517139
1
Roll Pin Shift Lever
10511666
1
29MT PACKAGE CONTENTS
Description
PART #
QTY
Torque Values
CE O-Ring
10510150
1
DE O-Ring
10510151
1
Retainer Ring Pinion
10510046
1
Pinion Retainer
10510045
1
Spring Pinion
10510044
2
Solenoid M Terminal Nut
10517179
1
7.3-9.3 Nm (64-82 lb in)
Solenoid S Terminal Nut
10517187
1
2.0-2.5 Nm (18-22 lb in)
Solenoid B+ Terminal Nut
10517190
1
15.0-18.0 Nm (11-13 lb ft)
Solenoid Screw
10517192
2
7.7-9.8 Nm (68-86 lb in)
Ball
10510082
1
Bolt IMS
10517131
2
7.7-9.8 Nm (68-86 lb in)
Bolt CE Frame
10517191
2
2.4-3.0 Nm (21-26 lb in)
Pin
10510138
1
Shift Lever Pin
10510074
1
IMS S Terminal Nut
10517170
1
3.9-5.1 Nm (35-45 lb in)
