Setting Up the Satellite Dish Antenna and Terrestrial Inputs
Page 4-9
After fine-tuning, highlighting the Done button and pressing the key on the remote control
will display the INSTALLATION screen. Highlighting the Video button and pressing the
key on the remote control will display the channel last viewed. You may also use the Exit key on
the remote control to exit all menus and return to the last viewed channel.
Terrestrial Antenna or Cable without
a Satellite Connection
If you connected a terrestrial antenna or local cable TV service to view local analog or digital
channels, you need to configure the HD receiver to receive these broadcasts.
Highlighting the Local Area button on the INSTALLATION screen and pressing the key
on the remote control will display the LOCAL AREA screen. Using the and keys, highlight
either the Local In 1 button if you connected your terrestrial antenna or cable service to the jack
labeled IN FROM ANT. Or, highlight the Local In 2 button if you connected your terrestrial
antenna to the jack labeled SATELLITE IN. Then press the
key on the remote control to
display the Local In pop-up menu.
On the Local In pop-up menu, use the and keys to highlight the buttons for the type of
connection made to the HD receiver, and then press the
key on the remote control.
Local In Connection Options
The connection options found on the Local In 1 and Local In 2 pop-up menus are:
None You are not connected to an antenna or cable.
Antenna You have connected a standard VHF/UHF indoor or outdoor antenna.
Cable TV (STD) You have connected a cable service that uses a standard type of cable signal.
Cable TV (HRC) You have connected a cable service that uses the HRC type of cable signal.
Cable TV (IRC) You have connected a cable service that uses the IRC type of cable signal.
Note: Consult your cable company to find out what type of cable signal you have.
After selecting your Local In connection and pressing the key on the remote control, the
LOCAL AREA screen will be displayed.
Note: Local In 1 and Local In 2 must have different input signal types. The
receiver does not support the simultaneous connection of two terrestrial
antenna signals or two cable signals.
