- 6 -
QSD004 User’s Manual
5.2 Camera Select
If a channel is disabled, the system will display “OFF” on the monitor, and this
channel will not be selected to record. (Refer to 5.3 Record Select)
5.3 Record Select
Configure which channels you want to record.
Note: If no channels are selected, an error message will appear briefly on
the screen when record is selected.
The DVR system can display 4
camera feeds in one picture (Quad Mode).
You can configure which cameras are
displayed.
Press [ SEL] to modify setting, or
press [CH1], [CH2], [CH3] and [CH4] to
select each channel separately.
[ Menu]: enter system menu
Note: If you are recording to enter
Menu you need to push stop button to
stop recording first.
[ Up] and [ Down]: move the cursor
[ SEL]: select/modify settings
[ Menu]: press again to exit
MAIN MENU
CAMERA SELECT 1 2 3 4
RECORD SELECT 1 2 3 4
RESOLUTION EACH
RECORD FRAME 25
RECORD QUALITY HIGH
SCHEDULE SET
MISCELLANEOUS MENU
HARD DISK SET
MOTION SET
VIDEO MODE PAL
FACTORY RESET
PRESS (UP ， ， ， ，DOWN), ENTER (SELECT)
PRESS (MENU) TO EXIT
