- 11 -
QSD004 User’s Manual
5.14 Motion Set
MOTION SET:
AREA SET:
Use [ Up] and [ Down] buttons to select the channel you want to modify,
press [ SEL] button to enter the sensitive area of each camera. The picture of the
selected channel is divided into 144(12*12) blocks, press [REW] to move left,
press [FWD] to move right, press[ Up] and [ Down] to move the cursor up and
down, press [ SEL] to set the block active or not.
When the block is transparent, it’s active to record. When the block is covered
by shadow, it is not active, and motion in this area will NOT be detected.
Make sure Record Schedule is set to Motion for the times required.
SENSITIVITY:
Use [ Up] and [ Down] button to
select the channel you want to modify,
press [ SEL] to adjust sensitivity of
motion detection on each channel.
High (1----------9, OFF) Low
When it’s “OFF”, the channel cannot
be triggered by motion.
MOTION RECORD TIME:
This number indicates how many
seconds the motion detection recording
continues after a motion triggered event
ends.
MOTION ALARM TIME:
This number indicates how many
seconds the buzzer inside the DVR will
sound after the DVR has been triggered
by motion.
CONT: Continuous alarm until press
any key to stop.
OFF: No alarm
MOTION SET
MOTION RECORD TIME: 10
MOTION ALARM TIME: OFF
MOTION SET
PRESS (UP, DOWN), ENTER (SELECT)
PRESS (MENU) TO EXIT
MOTION DETECTION SET
>CHANNEL 1 SENSITIVITY 4
CHANNEL 2 SENSITIVITY 4
CHANNEL 3 SENSITIVITY 4
CHANNEL 4 SENSITIVITY 4
CHANNEL 1 AREA SET
CHANNEL 2 AREA SET
CHANNEL 3 AREA SET
CHANNEL 4 AREA SET
PRESS (UP, DOWN), ENTER (SELECT)
PRESS (MENU) TO EXIT
