- 5 -
QSD004 User’s Manual
4.4 Main Screen
5.1 Setup Menu
Menu Directory
CAMERA SELECT
RECORD SELECT
RESOLUTION
RECORD FRAME
RECORD QUALITY
SCHEDULE SET
MISCELLANEOUS MENU
HARD DISK SET
MOTION SET
VIDEO MODE
FACTORY RESET
Chapter 5: DVR Setup
MAIN
MENU
＞ ＞ ＞ ＞
AUTO RECORD
PASSWORD ENABLE
PASSWORD CHANGE
COLOR SET
TIME SET
While the DVR is running, the
monitor will display the information from
the cameras as follows:
Upper left: Percentage of space used on
hard drive.
Middle: Channel number (CH1 through
CH4)
Bottom right: Date and Time
Bottom left: System status. (Refer to 6.1
Start Recording)
