16

PS1000D / PS1500D / PS2000D

1. RS-232 Interface Port

5. Output Socket

2. Intelligent Slot

(SNMP, optional)

6. External Battery Socket ( L )

3.

RJ11

Surge Protection

7. Breaker

4. Remote Control

8. Input Socket

17

PS1000D-RM / PS1500D-RM (1U)

1. RS-232 Interface Port

4. Output Socket (NEMA 5-15R or

IEC320)

2. Intelligent Slot

(SNMP, optional)

5.

Breaker

3. Remote Control

(optional)

6. Input Socket
