OPTI-UPS PS7500DL User Manual
Page 10

18
PS1000D-RT / PS1500D-RT / PS2000D-RT (2U)
1. RS-232 Interface Port
6. Fan
2. Intelligent Slot
(SNMP, optional)
7. External Battery Socket ( L )
3.
RJ11
Surge Protection
8. Breaker
4. Remote Control
(optional)
9. Input Socket
5. Output Socket (NEMA 5-15R or IEC320)
19
PS3000D-RT / PS3000DL Convertible Unit (3U)
1. RS-232 Interface Port
6. Fan
2. Intelligent Slot
(SNMP, optional)
7. External Battery Socket ( L )
3.
RJ11
Surge Protection
8. Breaker
4. Remote Control
(optional)
9. Input Socket
5. Output Socket (NEMA 5-15R or IEC320)
