Arm bracket
Qty: 1
WIRELESS EDGE
SHEET 1 OF 4
RD42661500C/REV-A
Spring washer M5
Qty: 4
Item: 3
Bolt M5x16
Qty: 4
MT-120018/A only
Bolt M8x40
Qty: 4
Wall/Poll bracket
Qty: 1
Antenna/enclosure
base bracket
Qty: 1
Item: 1
Washer spring M8
Qty: 4
Flat washer M5
Qty: 4
Item:2
Clamping bracket
Qty: 1
Washer flat M8
Qty: 4
Bolt M8x70
Qty: 2
Nut M5
Qty: 4
INSTALLATION INSTRUCTIONS
FOR MT-120018/A
Item: 4
Item: 5
Item: 10
Item: 8
Item: 6
Item: 12
Item: 13
Item: 11
Item: 9 Item: 7
Nut M8
Qty: 2
