38 Installation and Commissioning of the Unit Operating Manual Freeze Dryer ALPHA 1-4 LDplus / ALPHA 2-4 LDplus
ALPHA 1-4 LD
plus
ALPHA 2-4 LD
plus
Connection flange
Max. 5 shelves
Ø375 (unheated) Product dish
Drying vessel e.g.
injection bottle
Rubber valve
Drying chamber
Connection piece for rubber
valve to extend the drying
chamber, a max. of 18 pieces
Dying vessel e.g.
round bottom flask
Drying vessel
e.g. ampoule
Distributor
