9 13/16 in. (249 mm)
10 5/16 in. (262 mm)
7 3/4 in. (197 mm)
Livorsi DTS Controls
Contour Base
Quad Engine (8 handle)
When printing this
template, make sure
the page scaling options
have been disabled.
May not be to scale.
5 1/8 in. (130 mm)
Cutout Area
Overall Surface Area
When printing this template, be sure that page scaling options have been disabled.
For installation and operation instructions, please visit www.livorsi.com/tools.htm
