Livorsi DTS Controls - Manual (Page 15)

(86 mm) 3 3/8 in.
Overall Surface Area
Cutout Area
(73 mm) 2 7/8 in.
Livorsi DTS Controls
Flat Base
Single Engine (2 handle)
5 1/8 in. (130 mm)
7 3/4 in. (197 mm)
When printing this
template, make
sure the page
scaling options
have been
disabled.
May not be to
scale.
When printing this template, be sure that page scaling options have been disabled.
For installation and operation instructions, please visit www.livorsi.com/tools.htm
