Livorsi DTS Controls- Single/Dual Engine Installation APRIL 2012 Page 10 of 12
Control Connection Harness Connection
Starboard Shift Potentiometer “LEVER 1”
Port Shift Potentiometer “LEVER 2”
Starboard Throttle Potentiometer “LEVER 3”
Port Throttle Potentiometer “LEVER 4”
1. Connect the “LEVER 1” connector on the DTS command module harness to the
starboard control’s shift potentiometer
2. Connect the “LEVER 2” connector on the DTS command module harness to the
port control’s shift potentiometer
3. Connect the “LEVER 3” connector on the DTS command module harness to the
starboard control’s throttle potentiometer using the adaptor harness
(P/N 89-891963A01).
4. Connect the “LEVER 4” connector on the DTS command module harness to the
port control’s throttle potentiometer using the adaptor harness
(P/N 89-891963A01).
5. Connect the trim adaptor harness to the DTS command module harness.
6. Connect the bullet connectors on the trim adaptor harness to the trim
connections on the control.
7. Connect the six bullet connectors on the trim adaptor harness to the individual
trim switches on the dash or console. (optional)
8. Connect the start/stop switch (optional), lanyard stop switch, and key switches to
the appropriate connections, as shown.
9. Make all other DTS command module harness connections following the
instructions included with the DTS Command Module kit.
