4.13
WARNING: After calibration always check for proper operation of the slide adjust
system as wiring or transducer faults could cause an invalid calibration.
Bad measurements could result in damage to the machine and tooling,
and can cause injury or death.
h) The slide system should now be calibrated. Check for proper operation by running the slide
up near the top of the adjustment range and checking the slide position reported. Repeat this
process with the slide near the bottom of the adjustment range.
