Page 8 of 15

Addendum For E40 Controlled Vehicles

(see chart on pages 11 & 12 for vehicle applications)

WARNING - failure to use the supplied adapter harness or failure to wire the adapter harness

correctly can result in voltage being applied to the incorrect terminals to the TRG-002 and can

cause failure of the TRG-002. Damage to the TRG-002 due to incorrect wiring is NOT covered

under warranty.

E40 equipped vehicles use the GM Gen IV V8 engines but these engines still have the 24X crank gear

found on the Gen III engines. The camshaft position sensor is moved to the front timing cover on these

vehicles (just like the newer 58X engines) except the timing gear has a 1X reluctor with a single tooth

resulting in the same signal pattern as the camshaft mounted reluctor found on the Gen III engines.

On the Gen IV V8 Corvette, Trailblazer, SSR & other S/T platform vehicles, there is a jumper harness

attached to the timing cover that connects the cam sensor to the engine harness (see image on page 9).

On the E40 equipped 2005-2006 Pontiac GTO and Holden HSV vehicles the engine harness connects

directly to the cam sensor and no such jumper harness exists on the engines. Because of this difference

in factory wiring, the connection from the TRG-002 to the factory harness is different between these

two applications.

On E40 equipped vehicles the included E40 TRG camshaft output adapter harness (L480145305) must

be used between the TRG-002 Cam Out and the vehicle’s engine harness. The supplied camshaft adapt-

er harness has a connector already installed on one end that plugs into the TRG-002 Cam Out connector.

The “Engine Harness Cam E40” end has sealed terminals that need to be installed into the appropriate

connector for your vehicle application.

• Two connectors are included with the extension harness. See the images and diagrams on page 7 to

determine the correct connector for your vehicle.

• For all vehicles except the 2005-2006 Pontiac GTO and LS2 HSV applications, the 12129615

connector will be installed on the camshaft output adapter harness.

• For the 2005-2006 Pontiac GTO and LS2 HSV applications, the 12131195 connector will be

installed on the camshaft output adapter harness.

• The following pin-out should be used when terminating either connector (for both sets of vehicle

applications):

Pin

Wire Color

Circuit No.

Function

A

Red

631

12-volt reference

B

Black

632

Low reference

C

Green

633

CMP sensor signal

• The terminals will only go in the connectors one way and should be able to be inserted and locked

into position without any undue force. The letter markings for the pins are molded into each

connector.

• Once you have installed the wires into the connector, gently pull on the wires to make sure they are

properly seated and locked in the connector.

• Now install the terminal position assurance (TPA) component over the connector and wires (see

other TRG-002 harness connectors to see how this is done).
