Chapter 2: Prerequisites
Product Service 1-800-522-7658
4
Exhaust Requirements
If you intend to connect the Procedure Station to the optional Canopy
Connection Kit, first examine the location to ensure that it is compatible with
the cabinet’s exhaust duct. The area directly above the cabinet’s exhaust port
should be clear of structural elements, water and utility lines, or other fixed
obstructions. There should be enough clearance to accommodate a 10-inch
diameter duct. Avoid cabinet locations that require an elbow directly above
the cabinet’s exhaust connection or an excessive number of elbows in the
exhaust system. For further information about the cabinet’s exhaust system
requirements, please refer to Chapter 3: Getting Started.
Electrical Requirements
The different Biosafety Cabinet models have the following electrical
requirements:
Model #
Requirements
3480000-3480009
115 VAC, 60 Hz, 12 Amps
3480200-3480209
115 VAC, 60 Hz, 12 Amps
3480010-3480019
100 VAC, 50/60 Hz, 12 Amps
3480210-3480219
100 VAC, 50/60 Hz, 12 Amps
3480020-3480029
230 VAC, 50/60 Hz, 6 Amps
3480220-3480229
230 VAC, 50/60 Hz, 6 Amps
3481000-3481009
115 VAC, 60 Hz, 16 Amps
3481200-3481209
115 VAC, 60 Hz, 16 Amps
3481010-3481019
100 VAC, 50/60 Hz, 12 Amps
3481210-3481219
100 VAC, 50/60/ Hz, 12 Amps
3481020-3481029
230 VAC, 50/60 Hz, 8 Amps
3481220-3481229
230 VAC, 50/60 Hz, 8 Amps
Note: A dedicated outlet with a circuit breaker rated at 20 amps should
be located as close as possible to the right rear side of the cabinet, at a
height even with, or higher than, the top of the supporting structure.
Note: On 115 VAC models, both electrical outlets are protected by a ground
fault interrupter circuit (GFIC). Labconco does not recommend plugging the
Procedure Station into a GFIC outlet.
Table 2-1
