Chapter 5: Using The Cabinet
Product Service 1-800-522-7658 30
The Touchpad Controls
The touchpad of the Procedure Station is shown in Figure 5-4. Take a
moment to get familiar with the buttons, their location and function. Also
familiarize yourself with the display located on the right side wall. The
display will report system functions, such as filter capacity, timer displays,
alarm or error messages, as well as icons that illuminate when cabinet
functions such as UV light and blower are operational
Blower Button – Starts or stops the cabinet blower. When
the blower is in SmartStart
TM mode, closing the sash will
turn the blower off. When the sash is raised, the blower will
restart automatically. In NightSmart
TM mode, when the
sash is closed, the motor will slow to idle to maintain air
cleanliness in the work area. When the sash is reopened,
the blower will resume normal operation. Pressing this
button will override SmartStart
TM and NightSmart TM
operation.
Light Button – Turns the fluorescent lamps on or off.
Closing the sash will automatically turn the lights off.
When the lights are in SmartStart
TM mode, if the sash is
raised, the lights will turn on automatically.
UV Light Button – Turns the optional UV lamp on or off.
When the UV lamp is in SmartStart
TM mode, closing the
sash will turn the light on for the programmed period of
time. When the sash is raised, the lights will turn off
automatically.
Timer Button – Allows you to select either a repeating
interval timer, or an elapsed timer (stopwatch).
Mute/OK Button – Mutes all audible alarms for
approximately 5 minutes, unless it is a system error alarm.
When in the Menu mode, this button is used to select an
option.
Menu Button – This button toggles the display between
the display and menu modes. When in the menu mode,
pressing this button will return you to the previous menu
level.
Select Buttons – Allow you to choose different options in
the menu mode.
Figure 5-4
