Chapter 3: Getting Started
Product Service 1-800-522-7658 10
Telescoping Base Stands
These stands are available with either fixed feet or casters. Adjust the leg
height before installing the cabinet on top of the stand. The height can be set
in 1-inch intervals between 27.5 to 33.5 inches, providing a cabinet work
surface height from 30.0 to 36.0 inches. The Base Stands for each width
cabinet are listed in Table 3-1 below.
Width Base Stand w/Feet Model # Base Stand w/Casters Model #
4' 3730400 3730410
6' 3730600 3730610
1. Before positioning the Telescoping Base Stand in its final location, adjust
the height. A plastic bag containing the mounting bolts for the Procedure
Station is shipped with the base stand. Remove and save it.
2. Select the height of the stand and slide four (4) leg extensions into base
stand corner posts and attach with 2 ¼ inch long bolt, flatwasher,
lockwasher and nut. Ensure that the same height hole is selected for each
leg. Tighten the leg bolts securely. See Figure 3-1.
Table 3-1
Figure 3-1
