Labconco AtmosPure Re-Gen Gas Purifiers 5121845 User Manual
Page 41
Product Service 1-800-522-7658
37
C
C
h
h
a
a
p
p
t
t
e
e
r
r
7
7
:
:
A
A
c
c
c
c
e
e
s
s
s
s
o
o
r
r
i
i
z
z
i
i
n
n
g
g
Y
Y
o
o
u
u
r
r
G
G
a
a
s
s
P
P
u
u
r
r
i
i
f
f
i
i
e
e
r
r
There are many ways to accessorize the Gas Purifier for your use with the
glove box. These include many different accessories listed in this chapter.
1.
Adjustable Height Base Stands with Work Surface (Part
#5235500 w/casters, Part #5235501 w/adjustable feet)
These stands, 60" x 31", with attached black laminate work surfaces
have an adjustable height range from 33" to 40" (838mm-1,016mm)
and include a lower shelf for supporting accessory equipment. See
Figure 1-1.
2.
AtmosPure Roughing Pre-Filter Kit (Part #5441500)
Provides two roughing particulate pre-filters and clamp plates to
mount inside Protector Glove Boxes only. It is used to filter the inlet
and outlet of the glove box as the inert gas is purified.
3.
AtmosPure P100 Particulate Filter Kit (Part #5441600)
Provides two P100 particulate filters and mount housings that are
similar to respirator cartridges. It is used to filter the inlet and outlet
of the glove box as the inert gas is purified.
4.
AtmosPure Regeneration Plumbing Kit (Part #5441700)
The regeneration plumbing kit includes flexible tubing and fittings to
make all the regeneration tubing connections only. These are the
three connections to the 4% hydrogen inert gas mixture, vacuum, and
vent.
5.
AtmosPure Circulation Kits (see Part #’s below)
The circulation kits include all the plumbing to make connection from
the Gas Purifier to the glove box. There are options for neoprene
lined hose and hard ducted stainless steel.
Part #
Description
Used On
5441800
3/4" I.D. Neoprene lined hose All Glove Boxes, single width
5441801
3/4" I.D. Neoprene lined hose All Glove Boxes, double width
5441802
3/4" Rigid Stainless Steel
Protector Glove Boxes, single width
5441803
3/4" Rigid Stainless Steel
Protector Glove Boxes, double width
