Labconco CAptureTMPortable Fuming System 3420024 User Manual
Page 23

Chapter 5: Maintaining the System
Product Service 1-800-522-7658
19
4. Grasp the filter cartridge and pull the bottom of the cartridge until the
filter cartridge inlet pulls out of the filter cartridge seal. Keep pulling
the bottom of the cartridge out until it clears the back edge of the
heater/filter module, then pull it out of the flexible connector.
5. Discard the used cartridge, and install a replacement, by reversing the
removal steps.
6. Ensure that the filter cartridge seal has not been deformed during
installation of the new filter cartridge.
Resetting the Circuit Breaker:
To reset the circuit breaker located on the rear of steel system module, press
the switch to the “on” (I) position.
