Chapter 4: Using the System
Product Service 1-800-522-7658
16
10. Remove any evidence hooks or shelves from the stainless steel face
plate.
11. Wipe up any residue from the stainless steel face plate and the clear
chamber.
12. Unplug the unit. Stow the foam storage insert and the accessories in
the bottom of the clear chamber.
13. Raise the leveling foot to the up position by pulling the pin out, and
sliding the foot up until the pin sets, as shown in Figure 4-4.
14. Place the heater/filter module into the clear chamber, ensuring that is
fits into the chamber completely.
15. Place the transport lid back on top of the stainless steel face plate, and
reengage the two clamps securing the transport cover to the clear
chamber. The unit is now ready for transport or storage.
