HITEC X2 Ultima: DC/DC, 200 Watt, Dual Port Multi-Charger User Manual

Page 8

These warning and safety notes are particularly important. Please follow the

instructions for maximum safety; otherwise the charger and the battery can

be damaged or at worst, cause a fire.

Never leave the charger unattended when it is connected to its power supply. If

any malfunction is found, TERMINATE THE PROCESS AT ONCE and refer to the

operation manual.

Keep the charger well away from dust, damp, rain, heat, direct sunshine and

vibration. Never drop it.

The allowable input voltage is 11~18V DC.

This charger and the battery should be put on a heat-resistant, non-flammable

or non-conductive surface. Never place them on a car seat, carpet or similar

material. Keep all flammable, volatile materials away from the operating area.

Make sure you know the specifications of the battery to be charged or discharged

to ensure it meets the requirements of this charger. If the program is set up

incorrectly, the battery and charger may be damaged .Overcharging can cause a

fire or explosion. This warranty is not valid for any damage or subsequent damage

arising as a result of a misuse or failure to observe the procedures outlined in

this manual.

WARNING AND SAFETY NOTES

Standard Battery Parameters

Be very careful to choose the correct voltage for different types of batteries; otherwise

you may cause damage to the batteries. Incorrect settings could cause the cells to

catch fire or explode.

3.7V/cell

Nominal

Voltage

Min. Discharge

Voltage

Max Charge

Voltage
Storage

Voltage
Allowable

Fast Charge

3.7V/cell

4.2V/cell

3.8V/cell

3.0V/cell

LiPo

LiIon

3.6V/cell

4.1V/cell

2.5V/cell

3.3V/cell

3.6V/cell

3.3V/cell

2.0V/cell

LiFe

1.2V/cell

1.5V/cell

n/a

1C-2C

0.85V/cell

NiCd

1.2V/cell

1.5V/cell

n/a

1C-2C

1.0V/cell

MiMH

2.0V/cell

2.46V/cell

n/a

0.4C

1.75V/cell
