HITEC X2 Ultima: DC/DC, 200 Watt, Dual Port Multi-Charger - Manual (Page 15)

DEC INC DEC INC
INC DEC
DEC INC DEC INC
DEC INC
INC DEC
An optional feature uses the temperature probe contacting
the surface of the battery. The temperature cut-off can be on
or off. If it is on, set the maximum temperature at which the
charger should allow the battery to reach during charge.
Once a battery reaches this temperature during the charge,
the process will be terminated to protect the battery.
A battery on the cyclic process of charge and discharge
can often become warm after the charge or discharge period.
The program can insert a time delay after each charge and
discharge process to allow the battery adequate time to cool
down before continuing to the next process. The value
ranges from 1 to 60 minutes.
You can set the trickle charge mode to on or off. If it is on,
the charger will automatically supply the trickle charge
current to achieve a full charge without overheating the
battery after the fast charge has been terminated.
When you start a charge process, the integral safety timer
automatically starts running at the same time.This is
programmed to prevent overcharging of the battery if it
proves to be faulty or if the termination circuit cannot detect
the battery in full. The value for the safety timer should be
generous enough to allow a full charge of the battery.
This program sets the maximum charge capacity that will be
supplied to the battery during charging. If the delta-peak
voltage is not detected or if the safety timer expires for any
reason, this feature will automatically stop the process at the
selected capacity value.
The beep sounds every time a button is pressed to confirm
your action. The beep or melody sounds at various times
during operation to alert you to different mode changes.
These audible sounds can be turned on or off.
This program monitors the voltage of the input battery. If the
voltage drops below the set value, the operation will be
forcibly terminated to protect the input battery.
You can adjust the brightness of the charger's LCD screen.
INITIAL PARAMETER SET UP (USERS SET UP)
DEC INC
INC DEC
INC DEC
DEC INC
DEC INC DEC INC
DEC INC DEC INC
INC DEC
DEC
INC
INC DEC
14
