DISCHARGE OF NICD/NIMH BATTERY
Discharge of NiCd/NiMH battery
Discharge
current
This screen indicates the discharging state. You can press
the Start/Enter key to alter the discharge current. Press the
Start/Enter key again to store the value. Press the Batt
Type/Stop key to stop discharging. A sound will emit to
indicate the end of discharging.
Battery
type
Battery
voltage
Elapsed
time Discharged
capacity
Batt type
Stop
Start
Enter
DEC INC DEC INC
Set the discharge current on the left and the final voltage
on the right. The range of the discharge current is 0.1
~5.0A; the range of the final voltage is 0.1~25.0V. Press
the Start/Enter key for more than 3 seconds to start the
program.
- + - +
Charge/discharge and discharge/charge cycle of NiCd/NiMH battery
You can set the sequence on the left and the number
of cycles on the right. The range of the cycle number
is 1-5.
DEC
-
Batt type
Stop
INC
+
DEC
Start
Enter
-
INC
+
Press the Batt Type/Stop key to stop the program, You
can press the Start/Enter key to alter the charge current.
A sound will emit to indicate the end of the program.
Battery
type
Elapsed
time
Battery
voltage
Discharged
or charged
capacity
Discharge
or charge
current
When it approaches the end, you can see the capacity of
the battery being charged or discharged. You can press
the Inc or Dec key to display the result of each cycle.
21
'> 3 seconds'
'> 3 seconds'
