Charging Lithium battery in the fast charge mode
CHARGING LITHIUM BATTERY IN THE FAST CHARGE MODE
INC INC DEC DEC
- - + +
Start
Enter
Start
Enter
Batt type
Stop
The charging current gets smaller as the process nears the end term of the Lithium
battery charging process. To finish the charging process earlier, this program
eliminates certain terms of the CV process. Actually, the charging current will go
to 1/5 from the initial value to end the process while the normal charging goes to
1/10 during the CV term. The charging capacity may be a bit smaller than normal
charging but the process time will be reduced.
Current
voltage
battery
Supplied
capacity
Charge
current
Charging
time Number
of
cells
18
'> 3 seconds'
The value on the left side of the second lines sets the
charge current. The value on the right side of the
second line sets the battery pack's voltage. After
setting the current and voltage, press the Start/Enter
for more than 3 seconds to start the process.
This displays the number of cells you set up and the
processor detects. “R” shows the number of cells
detected by the charger and “S” is the number of cells
set by you at the previous screen. If both numbers are
identical, you can start charging by pressing the
Start/Enter button. If not, press the Batt Type/Stop
button to go back to the previous screen. Carefully
check the number of cells of the battery pack before
proceeding.
This screen shows the real-time status during the
charge process. Press the Batt Type/Stop key once
to stop the charge process.
