Factory Preset COM Port Numbering
Hatteland Display offer a wealth of options resulting in many Operating System numbered COM ports. The table
below lists all known ports that are assigned if a specific factory option (or duplicates of them) were factory mounted
prior to manufacturing and delivery of units to customer. Internal on-board, PCI based cards and Modules are listed.
Color codes are referring to indications from previous page.
COM Port # On-board/factory option Description
1
RS-232
Onboard
2
RS-485/422
Onboard
3
Intel AMT
Onboard, Intel Active Management Technology 9.0
7-10
CP114UL-I
PCI Card, Serial Communication COM 4 Ports Isolated, RS-232/422/485
19
HT 00268 OPT-A1
Digital IO Isolated, 4 Output + 4 Input Module
20
HT 00254 OPT-A1
CAN isolated, 2 channel Module
41-44
45-48
49-52
PCA100293-1 - Card #1
PCA100293-1 - Card #2
PCA100293-1 - Card #3
4 x RS-422/RS-485 NMEA Isolated / ECDIS Module
4 x RS-422/RS-485 NMEA Isolated / ECDIS Module
(pending)
4 x RS-422/RS-485 NMEA Isolated / ECDIS Module
(pending)
