Page 3: Front view, Right side, Back view, Top view
105706-01B
For more information, visit www.desatech.com
For more information, visit www.desatech.com
3
3
FRONT VIEW
30"
(76cm)
(Opening)
23
5
/
8
"
(60cm)
25" (64cm)
RIGHT SIDE
22
5
/
8
"
(57cm)
43
1
/
8
"
(110cm)
32" (81cm) (Opening)
1
7
/
8
"
(5cm)
1
1
/
4
"
(3cm)
BACK VIEW
39
3
/
4
"
(101cm)
26
3
/
8
"
(67cm)
3" (8cm)
1" (3cm)
2" (5cm)
3" (8cm)
22
5
/
8
"
(57cm)
34
3
/
4
"
(88cm)
TOP VIEW
(Left Side)
(Right Side)
(Front)
(Back)
23
5
/
8
"
(60cm)
11
15
/
16
"
(30cm)
10
1
/
2
"
(27cm)
1.5"ø
(4cm)
1.5"ø
(4cm)
11
1
/
8
"
(28cm)
Back of
Surround
Rating Plate
Location
Left Side
Surround
Right Side
Surround
Alternate Gas
Supply Inlets
Figure 2 - VDVF36STN/STP (See-Thru) Dimensions
GLOSSARY OF TERMS
Chase
- A box-like enclosure to protect venting from the elements
when the venting run is on the outside of a structure.
Mastic
- A pliable sealant for use around the vent terminal.
Snorkel Termination
- A box that raises the horizontal termina-
tion above ground level clearances.
Vent Terminal
- Mounted on an outside wall or roof to separate the
inlet and outlet of the vent system and protect it from weather.
Vinyl Siding Standoff
- A metal box that separates the vent cap
from vinyl siding.
Wall Thimble/Firestop
- A metal plate used to secure the vent
pipe when it passes through a wall or ceiling.
PRODUCT DIMENSIONS
Continued
PRODUCT DIMENSTIONS
GLOSSARY OF TERMS
