19 18
Code Valid Values Default PW
71 Baud rate 1200, 2400, 4800, 9600 4800 yes
72 Cleaning timer 0 to 19999 days 0 no
73 Initial cleaning day 01 to 31 01 no
74 Initial cleaning month 01 to 12 01 no
75 Initial cleaning year 1998 to 9999 1998 no
76 Initial cleaning time 00:00 to 23:59 00:00 no
77 Cleaning ON interval 0 to 19999 minutes 0 no
90 Display selftest 0: off 0 yes
1: on
91 Keyboard selftest 0: off 0 yes
1: on
92 EEPROM selftest 0: off 0 yes
1: on
93 Relays and LEDs selftest 0: off 0 yes
1: on
94 Watchdog selftest 0: off 0 yes
1: on
99 Unlock password 0000 to 9999 0000 yes
Note The process controller automatically checks to ensure that
the entered data matches other related variables. If a wrong
configuration is entered, “ERROR” blinks on the LCD to
prompt the user. The correct configurations are the follow-
ing:
If M1= / 0 then S1 HA, S1 LA;
If M2= / 0 then S2 HA, S2 LA;
If M1= 1 then S1-H1 LA;
If M1= 2 then S1+H1 HA;
If M1= 3 then S1+D1 HA;
If M1= 4 then S1-D1 LA;
Code Valid Values Default PW
21 Relay 2 mode (M2) same as relay 1 0 no
22 Relay 2 setpoint (S2) 0.5 to 99.5% full scale 75% f.s. no
23 Relay 2 hysteresis (H2) 0 to 5% f.s. 1% f.s. no
24 Relay 2 deviation (D2) 0.5 to 10% f.s. 1% f.s. no
25 Relay 2 reset time 0.1 to 999.9 minutes 999.9 no
26 Relay 2 rate time 0.0 to 999.9 minutes 0.0 no
30 Alarm relay 0.5 to 99.5% full scale 95% f.s. no
High Alarm (HA) HA-Hys LA + Hys,Hys = 1.5%f.s.,HA S1 or HA S2
31 Alarm relay 0.5 to 99.5% full scale 5% f.s. no
Low Alarm (LA) LA + Hys HA-Hys,Hys = 1.5%f.s.,LA S1 or LA S2
32 Proportional control 1 to 30 min 5 no
mode period
33 Maximum relay ON time 1 to 10 min 10 no
(after which an alarm mode is entered)
34 Alarm mask time 00:00 to 30:00 00:00 no
40 Analog output selection 0: 0-1mA 2 no
1: 0-20 mA
2: 4-20 mA
3: 0-5 VDC
4: 1-5 VDC
5: 0-10 VDC
41 Analog output 0 to 100% full scale 0 no
lower limit (O_VARMIN) (O_VARMIN O_VARMAX - 5% f.s.)
42 Analog output 0 to 100% full scale 100% f.s. no
upper limit (O_VARMAX) (O_VARMIN O_VARMAX - 5% f.s.)
60 Current day 01 to 31 from RTC no
61 Current month 01 to 12 from RTC no
62 Current year 1998 to 9999 from RTC no
63 Current time 00:00 to 23:59 from RTC no
