Hanna Instruments mV 600 Series - Manual (Page 30)

59 58
ORP ELECTRODES
½‘’ thread, double PVDF junction, polymer filled, max operating pressure of 6 bar (87
psi)
PLATINUM ELECTRODES
Part Code Matching Pin Amplifier Connector Cable
HI 2002/3 NO NO BNC 3 m (10’)
HI 2002/5 NO NO BNC 5 m (16.5’)
HI 2003/3 YES NO BNC* 3 m (10’)
HI 2003/5 YES NO BNC* 5 m (16.5’)
HI 2004/5 YES YES spade lugs* 5 m (16.5’)
GOLD ELECTRODES
Part Code Matching Pin Amplifier Connector Cable
HI 2012/3 NO NO BNC 3 m (10’)
HI 2012/5 NO NO BNC 5 m (16.5’)
HI 2013/3 YES NO BNC* 3 m (10’)
HI 2013/5 YES NO BNC* 5 m (16.5’)
HI 2005/5 YES YES spade lugs* 5 m (16.5’)
* In addition to the electrode connector, there is also a spade lug connection for the
matching pin
OTHER ACCESSORIES
BL PUMPS Dosing pumps with flow rate from 1.5 to 20 lph
HI 98501 ChecktempC Electronic thermometer (range -50.0 to 150.0°C)
HI 98502 ChecktempF Electronic thermometer (range -58.0 to 302°F)
HI 6050 & HI 6051 Submersible electrode holders
HI 6054 & HI 6057 Electrode holders for in-line applications
HI 778P Screened coaxial cable with screw connectors
HI 7871 & HI 7873 Level controllers
HI 8427 pH/ORP electrode simulator
HI 8614 pH transmitter
HI 8614L pH transmitter with LCD
HI 8615 ORP transmitter
HI 8615L ORP transmitter with LCD
HI 920010 RS232 connection cable
HI 92500 Windows ® compatible software
HI 931001 pH/ORP electrode simulator with LCD
HI 931002 4-20 mA simulator
